INCH-POUND
MIL-DTL-28875/5A
24 August 2000
SUPERSEDING
MIL-A-28875/5
27 July 1983
DETAIL SPECIFICATION SHEET
AMPLIFIERS, RADIO-FREQUENCY AND MICROWAVE, SOLID-STATE,
LOW NOISE, WIDEBAND, TO CONFIGURATION
This specification is approved for use by all Depart-
ments and Agencies of the Department of Defense.
The requirements for acquiring the amplifiers described herein shall
consist of this specification sheet and the latest revision of MIL-DTL-28875.
Inches
Millimeters
Max
Min
Max
Min
B
N/A
.17
N/A
4.3
C
.455 dia
.445 dia
11.56 dia
11.30 dia
D
.510
.490
12.95
12.45
E
.019
.016
.48
.41
F
.160
.140
4.06
3.56
G
.310
.290
7.87
7.37
H
.160
.140
4.06
3.56
J
.310
.290
7.87
7.37
K
.05
N/A
1.3
N/A
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only (1.00 in = 25.4 mm).
FIGURE 1. Dimensions and configuration.
AMSC N/A
1 of 5
FSC 5985
DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited.
