MIL-DTL-28875/6B
Inches
Millimeters
Max
Min
Max
Min
K
.40 typ
-
10.2 typ
-
L
.57 typ
-
14.5 typ
-
NOTES:
1. Dimensions are in inches (see Table II).
2. Metric equivalents are given for general information only (1.00 inch = 25.4 mm).
3. Barrel diameter shall accept two turns of AWG NO. 24 wire.
FIGURE 3. Dimensions and configuration, dash numbers -03, -04, -07, -08, -10, -11, and -12.
3
